Description
Kränzle high-pressure cleaner hot water therm-RP 1400 combines state-of-the-art technology and first-class washing action with high working pressure and maximum water output. This high-pressure cleaner fights heavy soiling with a high water temperature of up to 140 °C in the steam stage. Features such as the safety valve, flow monitor, optical flame monitor, overcurrent release, pressure switch and low fuel switch ensure safe operation at all times, even when you as the user are not nearby. The device has a photocell to monitor the burner flame. In addition, overheating protection measures the temperature of the flue gas opening: if the temperature exceeds 260°C, the heating is automatically switched off. A further technical highlight of this power pack is the adjustable burner output via temperature or percentage output according to target specifications. This ensures precise work even with partial quantities and low temperatures. This hot water high-pressure cleaner with additional disinfecting effect is ideal for use in sectors such as construction and agricultural machinery, agriculture and animal husbandry.
The device is available with or without a hose reel, as well as with an optional stainless steel heating coil. Please select the model you require.
Special features
- Quick-change plug-in system
- Twist-Stop anti-twist protection
- First-class flushing effect at high working pressure
- Kränzle in-line pump
- Detergent suction - direct and without additional accessories
- organizing system
- Digital temperature regulation
- Parking brake
- Service-friendly, removable hood
- Monitoring of safety-relevant functions
- Infinitely variable pressure regulation
- Direct suction: 2.5 m suction height
- Flow monitor
- Burner stop in case of fuel oil shortage
- Operating hours counter
- Fuel tank: 35 l
- Combustion chamber pre-ventilation
Technical data
High pressure cleaner:
- Working pressure: 70 - 170 bar / 7 - 17 MPa
- Water output: 23.3 l/min / 1400 l/h
- Permissible overpressure: 190 bar / 19 MPa
- Motor speed: 1400 rpm
- Connection: 400 V / 3 ~ / 50 Hz / 14.3 A
- Power consumption: 8.0 kW
- Power output: 6.3 kW
- Mains connection cable: 7.5 m
- Plug: CEE 32 A
- Dimensions (L/W/H):
1050 x 800 x 1015 mm (without hose reel)
1050 x 800 x 1300 mm (with hose reel) - Weight: 210 / 218 kg
Hot water:
- Hot water output: 12 - 80 °C (infinitely variable)
- Steam level max.: 140 °C
- Heating oil consumption max. heating capacity: 7.7 kg/h / 9.2 l/h
- Heating oil consumption ΔT 45°: 5.6 / 6.6 kW
- Heating output: 84 kW
Safety shut-off gun:
- Inlet: M22x1.5AG
- Outlet: Plug-in coupling D12
- Working pressure: 250 bar/ 25 MPa
- Water output: 40 l/min
- Max. temperature: 150
Scope of delivery
- 1 x Kränzle high-pressure cleaner hot water therm-RP 1400 included:
- 1 x high pressure hose 10 / 20 m (DN8)
- 1 x Starlet safety shut-off gun, short
- 1 x lance with flat jet nozzle, 100 cm length, handle, 08 nozzle size (red), 25° spray angle
- 1 x water inlet filter
