Description
Kränzle high-pressure cleaner hot water therm-RP 1000 provides powerful heat for the best cleaning power for stubborn dirt. The digital thermostat allows you to regulate the temperature and heat output to the exact degree. Operating mode 1: thermostat control in °C and operating mode 2: burner output in % are available for this purpose. The appliance also has a safety valve to protect against impermissibly high overpressure and a flow monitor that prevents the heating chamber from overheating if there is a lack of water. The overcurrent release switches off the high-pressure cleaner in the event of excessive power consumption and the optical flame monitor switches off the fuel supply when the burner flame goes out. Many technical innovations are combined in this hot water high-pressure cleaner to ensure maximum performance, reliability, safety and ease of use in daily use. This also includes the quick-change plug-in system, which ensures a safe and simple connection of the high-pressure gun and lance, as well as the total stop system to relieve the high-pressure pump.
This high-pressure cleaner is available with or without a hose reel and optionally with a stainless steel heating coil. Please select the model you require.
Special features
- Quick-change plug-in system
- Twist-Stop anti-twist protection
- First-class flushing effect at high working pressure
- Kränzle in-line pump
- Detergent suction - direct and without additional accessories
- organizing system
- Digital temperature regulation
- Parking brake
- Service-friendly, removable hood
- Monitoring of safety-relevant functions
- Infinitely variable pressure regulation
- Direct suction: 2.5 m suction height
- Flow monitor
- Burner stop in case of fuel oil shortage
- Operating hours counter
- Fuel tank: 35 l
- Combustion chamber pre-ventilation
Technical data
High-pressure cleaner:
- Working pressure: 70 - 200 bar / 7 - 20 MPa
- Water output: 16.6 l/min / 1000 l/h
- Permissible overpressure: 220 bar / 22 MPa
- Motor speed: 1400 rpm
- Connection: 400 V / 3 ~ / 50 Hz / 13.5 A
- Power consumption: 8.0 kW
- Power output: 6.3 kW
- Mains connection cable: 7.5 m
- Plug: CEE 32 A
- Dimensions (L/W/H):
1050 x 800 x 1015 mm (without hose reel)
1050 x 800 x 1300 mm (with hose reel) - Weight: 210 / 218 kg
Hot water:
- Hot water output: 12 - 80 °C (infinitely variable)
- Steam level max.: 140 °C
- Heating oil consumption max. heating capacity: 6.1 kg/h / 7.1 l/h
- Heating oil consumption ΔT 45°: 5.6 / 6.6 kW
- Heating output: 65 kW
Safety shut-off gun:
- Inlet: M22x1.5AG
- Outlet: Plug-in coupling D12
- Working pressure: 250 bar/ 25 MPa
- Water output: 40 l/min
- Max. temperature: 150
Scope of delivery
- 1 x Kränzle high-pressure cleaner hot water therm-RP 1000 included:
- 1 x high pressure hose 10 / 20 m (DN8)
- 1 x Starlet safety shut-off gun, short
- 1 x lance with flat jet nozzle, 100 cm length, handle shell, 05 nozzle size (turquoise), 25° spray angle
- 1 x water inlet filter
