Description
Kränzle hot water high-pressure cleaner therm 875-1 on all-terrain chassis and with full technical equipment - this professional device leaves nothing to be desired in terms of performance and handling. Here you get an extremely powerful and environmentally friendly hot water high-pressure cleaner, with or without integrated hose reel. It achieves an efficiency of approx. 93 %, which not only protects the environment, but also reduces fuel consumption and increases the achievable water temperatures, which ultimately leads to an improved cleaning result. Using the digital control panel, you can choose between operating mode 1 (thermostat control) and operating mode 2 (burner output). Operating mode 2 has the advantage over mode 1 that temperatures are maintained at +/- 1°C once the parameters have been determined. Even when operating with partial quantities and low temperatures. All the last values selected remain stored in the thermostats. In addition, all devices in the therm-1 series are already equipped with an operating hours counter as standard, which displays the number of operating hours of the high-pressure pump and burner unit. All you have to do is choose whether you want the appliance without or with a space-saving hose reel for your high-pressure hose.
Special features
- All-terrain chassis with parking brake and impact protection
- Pressure regulation
- Digital control panel
- order system
- Safety cut-out
- combustion chamber pre-ventilation
- Digital thermostat
- flow monitor
- Optical flame monitoring
- Overheating protection
- Burner stop in case of fuel oil shortage
- Operating hours counter
- Cleaning agent suction
- Water tank: 12 l volume
- Quick-change plug-in system
- Total stop system with delayed motor shutdown
Technical data
High-pressure cleaner:
- Working pressure: 30 - 175 bar / 3 - 17.5 MPa
- Water output: 14.6 l/min / 875 l/h
- Permissible overpressure: 190 bar / 19 MPa
- Motor speed: 1400 rpm
- Connection: 400 V / 3 ~ / 50 Hz / 8.7 A
- Power consumption: 4.8 kW
- Power output: 4.0 kW
- Mains connection cable: 7.5 m
- Fuel tank: 35 l
- Dimensions (L/W/H):
1050 x 800 x 1015 mm (without hose reel)
1050 x 800 x 1300 mm (with hose reel) - Weight: 197 / 205 kg
Hot water:
- Hot water output: 12 - 87 °C (infinitely variable)
- Steam level max.: 155 °C
- Heating oil consumption max. heating capacity: 5.8 kg/h / 6.8 l/h
- Heating oil consumption ΔT 45°: 4.2 / 5.0 kW
- Heating output: 60 kW
Safety shut-off gun:
- Inlet: M22x1.5AG
- Outlet: Plug-in coupling D12
- Working pressure: 250 bar/ 25 MPa
- Water output: 40 l/min
- Max. temperature: 150
Scope of delivery
- 1 x Kränzle high pressure cleaner hot water therm 875-1 included:
- 1 x high pressure hose 10 / 20 m (DN8)
- 1 x Starlet safety shut-off gun, short
- 1 x lance with flat jet nozzle, 100 cm length, handle, 045 nozzle size (green), 25° spray angle
- 1 x water inlet filter
