Description
Kränzle cold water high-pressure cleaner HD 9/80 TS with total stop and quick-change plug-in system developed for continuous professional use. This device has all the features of a professional device and is ideal for users with little storage space, but who do not want to compromise on quality. The large stainless steel pressure gauge allows you to keep an eye on the continuously adjustable working pressure at all times and this model has a direct detergent suction system as standard - without additional accessories. Even stubborn dirt can be perfectly removed using the injector method and the use of special cleaning agents, as well as with the lance with dirt killer supplied. Thanks to the additional pressure switch, the appliance switches off automatically when the high-pressure gun is closed and switches on again when it is opened. This protects all components and reduces wear.
Here you get an absolute professional device for the small yellow bag.
Special features
- Quick-change plug-in system D12
- Detergent suction
- Total stop system
- Pressure regulation
- Compact design
Technical data
High-pressure cleaner:
- Working pressure: 30 - 80 bar | 3 - 8 MPa
- Water output: 9 l/min | 540 l/h
- Permissible overpressure: 90 bar | 9 MPa
- Motor speed: 1400 rpm
- Connection: 230 V | 1 ~ | 50 Hz | 7.5 A
- Power consumption: 1.6 kW
- Power output: 1.0 kW
- Mains connection cable: 5 m
- Dimensions (L/W/H): 470 x 230 x 320 mm
- Weight: 24 kg
Safety shut-off gun:
- Inlet: M22x1.5AG
- Outlet: D12 plug-in coupling
- Working pressure: 207 bar/ 27 MPa
- Water output: 30 l/min
- Max. temperature: 150
Scope of delivery
- 1 x Kränzle cold water high-pressure cleaner HD 9/80 TS included:
- 1 x high pressure hose 10 m (DN6)
- 1 x safety shut-off gun M2000 - long
- 1 x lance with control nozzle, 042 nozzle size (yellow), 50 cm length, 20° spray angle
- 1 x lance with dirt killer, 042 nozzle size (yellow), 50 cm length
